Purpose and Scope

a. The basic element of the graphic language of the engineer are described and discussed in TM 5-581A. These include shape and size descriptions, projection and pictorial drawings, and line and format conventions. The purpose of this manual is to show the professional application of the elements, rules, and methods of this graphic language.

b. This manual contains the information required in applying the construction draftsman military occupational specialty (both specialist and noncommissioned officer). It covers topographic and site plans ; building drawings and wood construction plans ; masonry, concrete and steel structural plans ; machine and utility drawings ; road, railroad, airfield, heliport, and port construction plans ; material estimates ; construction in the theater of operations; and drafting room operations.
