AS B213-1966 PDF

Specifies dimensions of involute splined shafts and holes with a 30 degrees pressure angle. Basic formulas for calculating dimensions and tolerances are included, with guidance on obtaining the fit desired. Terms used are defined. The Standard also describes methods of gauging and inspecting splines, with methods of obtaining dimensions and tolerances for gauges. Inspection of splines using pins is covered and tables of measurements over and between pins are included.

Edition :	1st
File Size :	1 file , 4.5 MB
Note :	This product is unavailable in Ukraine, Russia, Belarus
Number of Pages :	76
Product Code(s) :	10087924, 10087918, 10087933
Published :	01/01/1966
