This report analyzes four flange tap equations and three corner tap equations for the discharge coefficient
for orifice plates. All of the equations analyzed are functions of Beta Ratios, Reynolds Number, and Line
Size, and all data points were evaluated against each of the seven orifice flow coefficient equations
described in more detail herein. The goals of the study were to review the data available to determine where
any weak regions of the database may be, to provide a methodology for comparing the equations over a
range of Reynolds Numbers, Line Sizes, and Beta Ratios, and to determine the performance of each
equation in relationship to the appropriate available database of calibration data.
| File Size : | 1
file
, 4.8 MB |
| ISBN(s) : | 9780791871782 |
| Note : | This product is unavailable in Ukraine, Russia, Belarus |
| Number of Pages : | 93 |
| Published : | 06/27/2018 |
