ASTM A875/A875M-13 PDF

1.1 This specification covers steel sheet, in coils and cut lengths, metallic-coated by the hot-dip process, with zinc-5 % aluminum alloy coating. The Zn-5Al alloy coating also contains small amounts of elements other than zinc and aluminum that are intended to improve processing and the characteristics of the coated product.

1.2 The coating is produced as two types: zinc-5 % aluminum-mischmetal alloy (Type I) and zinc-5 % aluminum-0.1 % magnesium alloy (Type II), and in two coating structures (classes). The coated sheet is produced in several coating designations (coating weight [mass]).

1.3 The material is intended for applications requiring corrosion resistance, formability, and paintability.

1.4 The steel sheet is produced in a number of designations, types, grades, and classes designed to be compatible with differing application requirements.

1.5 Coated sheet material furnished under this specification shall conform to the applicable requirements of the latest issue of Specification A924/A924M, unless otherwise provided herein.

1.6 The text of this specification references notes and footnotes that provide explanatory material. These notes and footnotes, excluding tables and figures, shall not be considered as requirements of this specification.

1.7 This specification is applicable to orders in either inch-pound units (as A875) or metric (SI) units [as A875M]. Values in inch-pound and SI units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system are not exact equivalents. Therefore, each system shall be used independently of the other.

1.8 Unless the order specifies the “M” specification designation (SI units), the material shall be furnished to inch-pound units.

1.9 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety and health practices and determine the applicability of regulatory limitations prior to use.
