Name: BS QC 221200:1997 PDF
Brand: BSI Group
SKU: bs-qc-221200-1997_1109931
Price: 110.49 EUR
Availability: InStock

Name:
BS QC 221200:1997 PDF

Published Date:
01/15/1997

Status:
Active

Description:

Radio-frequency connectors. RF coaxial connectors with inner diameter of outer conductor 6,5 mm (0,256 in) with bayonet lock. Characteristic impedance 50 ohms (Type BNC)

Publisher:
BSI Group

Document status:

Active

Format:

Electronic (PDF)

Delivery time:

10 minutes

Delivery time (for Czech version):

200 business days

SKU:

bs-qc-221200-1997_1109931

Radio-frequency (RF) coaxial connector patterns used with RF cables. These connector patterns are for low power, quick disconnect applications using bayonet type coupling mechanism and are commonly known as type BNC.

Cross References: BS 2011:Part 2.1.Ca*BS 2011:Part 2.1 Ka*BS 2011:Part 2.1M*BS 2011:Part 2. 1N*BS 2011:Part 2. 1T *BS 3041:Part 1*BS EN 60068-2-1*BS EN 60068-2-2 *BS EN 61169-1*

File Size :	1 file , 1.6 MB
ISBN(s) :	0580263789
Note :	This product is unavailable in Ukraine, Russia, Belarus
Number of Pages :	56
Product Code(s) :	1376942, 1376942, 01376942
Published :	01/15/1997

BS QC 221200:1997 PDF

Radio-frequency connectors. RF coaxial connectors with inner diameter of outer conductor 6,5 mm (0,256 in) with bayonet lock. Characteristic impedance 50 ohms (Type BNC)
