This part of IEC 61869 provides all requirements specific to voltage transformers to be used in DC applications (DCVTs), whatever the technology used. The output signal can be analogue or digital.
It is applicable to newly manufactured voltage transformers used for measuring, protection and/or control applications in DC power systems with a rated voltage above 1,5 kV.
This document covers passive voltage dividers as well as active voltage transformers, used for measurement, control and protection.
The general configuration of a single-pole low-power instrument transformer is described in Figure 601 of IEC 61869-6:2016.
Cross References:EN 61869-6:2016
IEC TS 60815-4:2016
IEC/TS 60815-4:2019
IEC TS 61245
IEC 61869-9:2016
EN 61869-1:2009
IEC 61869-1:2007
EN IEC 61869-9:2019
IEC 61869-6:2016
IEC TS 61245:2015
IEC 60358-1:2012
IEC 60050-351:2013/AMD1:2016
IEC 60050-471:2007/AMD1:2015
EN 60358-1:2012
IEC 60050-471:2007
IEC 60050-351:2013
All current amendments available at time of purchase are included with the purchase of this document. | File Size : | 1
file
, 1.6 MB |
| ISBN(s) : | 9780580879982 |
| Note : | This product is unavailable in Ukraine, Russia, Belarus |
| Number of Pages : | 40 |
| Product Code(s) : | 30312881, 30312881, 30312881 |
| Published : | 07/12/2019 |
