CEI EN 61788-6 PDF

This part of IEC 61788 covers a test method detailing the tensile test procedures to be carried out on Cu/Nb-Ti superconductive composite wires at room temperature.

This test is used to measure modulus of elasticity, 0,2 % proof strength of the composite due to yielding of the copper component, and tensile strength.

The value for percentage elongation after fracture and the second type of 0,2 % proof strength due to yielding of the Nb-Ti component serves only as a reference (see Clauses A.1 and A.2).

The sample covered by this test procedure has a round or rectangular cross-section with an area of 0,15 mm² to 2 mm² and a copper to superconductor volume ratio of 1,0 to 8,0 and without the insulating coating.
