Name:
DANSK DS/EN IEC 60317-74 PDF
Published Date:
04/24/2018
Status:
[ Active ]
Publisher:
Dansk Standard
IEC 60317-74:2018 specifies the requirements of enamelled rectangular aluminium winding wire of class 180 with a sole coating based on polyesterimide resin, which can be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements. NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics. The range of nominal conductor dimensions covered by this standard is: - width: min. 2,0 mm – max. 16,0 mm; - thickness: min. 0,80 mm – max. 5,60 mm. Wires of grade 1 and grade 2 are included in this specification and apply to the complete range of conductors. The specified combinations of width and thickness as well as the specified width/thickness ratio are given in IEC 60317-0-9:2015. Keywords: insulated wires used for windings
| Edition : | 18# |
| File Size : | 1 file , 2.9 MB |
| Number of Pages : | 15 |
| Product Code(s) : | DS-013, DS-013 |
| Published : | 04/24/2018 |
