DANSK DS/EN IEC 62271-212 PDF

This part of IEC 62271 specifies the service conditions, rated characteristics, general structural requirements and test methods of the assemblies of the main electrical functional units of a high-voltage transformer substation, duly interconnected, for AC voltages up to and including 52 kV on the high-voltage side and service frequency 50 Hz or 60 Hz. The CEADS is cable-connected to the high-voltage network for indoor and outdoor applications of restricted access. A CEADS as defined in this document is designed and tested to be a single product with a single serial number and one set of documentation. The functions of a CEADS are: – high-voltage/high-voltage or high-voltage/low-voltage transformation; and some or all the following: – switching and control for the operation of the high-voltage circuit(s); – switching and control for the operation of the low-voltage circuit(s); – protection of the power transformer functional unit. The main functions are integrated in the following functional units: – high-voltage functional unit; – power transformer functional unit; – low-voltage functional unit. NOTE – For the purpose of this document a self-protected transformer is not considered as a CEADS, but as a functional unit, designed and type tested to its own product standard IEC 60076-13:2006.
