This specification covers the basic requirements for nickel chromium plating on stainless steel. Nickel-chrome plating on other metals is covered by GMW14672.

Material Description.

Not applicable.

Symbols.

Not applicable.

Applicability.

Code A.

Primarily applicable to exterior fasteners, moldings and other trims made of austenitic stainless steel (300 series per SAE J405 or regional equivalent). The stainless substrates may not need buffing and provide excellent color match for surrounding plated trim. Coating consists of four (4) layers; a woods nickel strike (necessary for proper adhesion of plating to stainless), bright-nickel, microporous nickel, and chromium.

Code C.

Chrome flash finish for color match only and may be used for exterior or interior applications.

Code F.

Primarily applicable to exterior and interior moldings and other trims made of Ferritic Stainless Steel (Types 434 – Unified Numbering System (UNS) S43400 and 436 - UNS S43600). The stainless steel substrates may not need buffing and provide excellent color match for surrounding plated trim. Coating consists of four (4) layers which include a woods nickel strike, bright nickel, microporous nickel, and chromium.

Remarks.

Type 434 and Type 436 stainless steel, as well as those used with Code C, Code D, and Code E (chrome flash), normally require mechanical finishing (pre-buff strip, part buffing) to meet component appearance requirements. The mechanical finishing requirements shall be agreed upon between stainless steel supplier and user.
