Note: Nothing in this standard supercedes applicable laws and regulations.

Note: In the event of conflict between the English and domestic language, the English language shall take precedence.

Purpose/Material Description.

This steel shall be made by a GM approved steel making practice, such as the electric arc furnace or the basic oxygen process. This steel shall be continuously cast. The subsequent refining processes shall include the use of secondary ladle refining and the use of silicon for deoxidation purposes. The resulting inclusions shall be predominantly of a deformable nature. This material is considered super clean steel.

Symbols.

Not applicable.

Applicability.

Engine valve springs.

Remarks.

This specification covers three grades of special quality round and multi-arc steel wire intended for the manufacture of valve springs requiring resistance to set when used at moderately elevated temperatures and high stress levels. This wire shall be in either the quenched and tempered condition or annealed and cold drawn condition as specified by the purchaser.

• Type A wire has the lowest tensile strength.

• Type B wire is an intermediate tensile strength grade

• Type C wire is a high tensile strength grade.
