Description:

Semiconductor Device, Transistor, NPN, Silicon, Power, Type 2N6249, 2N6249T1, 2N6249T3, 2N6250, 2N6250T1, 2N6250T3, 2N6251, 2N6251T1, 2N6251T3, JAN, JANTX, JANTXV

Publisher:
Military Specifications and Standards

Document status:

Active

Format:

Electronic (PDF)

Delivery time:

10 minutes

Delivery time (for Czech version):

200 business days

SKU:

mil-mil-prf-19500-510k_2043038

MIL-PRF-19500/510K covers the performance requirements for NPN silicon, power transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type. Provisions for radiation hardness assurance (RHA) to eight radiation levels is provided for JANS and JANKC product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.
