BMI MMPDS-2024, Volume I, Chapter 8 PDF

This chapter, while comprising three major parts, primarily is concerned with joint allowables. Part 8.1 is concerned with mechanically fastened joints; Part 8.2, with metallurgical joints (various welding and brazing processes). Part 8.3 contains information for structural component data; it is concerned with bearings, pulleys, and cables.

With particular reference to Part 8.1, the introductory section (8.1.1) contains fastener indexes that can be used as a quick reference to locate a specific table of joint allowables. Following this introductory section are five sections comprising the five major fastener categories.

In each of the five major sections, there are subsections that describe the factors to be considered in determining the strength of fasteners and joints. After each major section, pertinent tables are presented.

Similarly, Part 8.2 has an introductory section (8.2.1), followed by two major sections comprising different metallurgical joints.

Following each 4-digit section, applicable tables and figures for the particular section are presented.

NOTE: This document contains design information on the mechanical and physical properties of metallic materials and joints commonly used in aircraft and aerospace vehicle structures. All information contained in this Handbook has been reviewed and approved using a standardized process. The development and ongoing maintenance process involves certifying agencies, including the FAA, DoD, and NASA, and major material suppliers and material users worldwide. The information and procedures in this Handbook are continuously reviewed, and modified or removed as determined to be appropriate. With advances in materials and fastener systems, and with the review process of existing information, periodic updates of the MMPDS should be expected. As such, it is recommended that the latest version of the MMPDS be used.

Included with Purchase: MMPDS-2024, Volume I: Conventional Materials and Joint Allowables, Appendices A-E
