Name:
SMPTE OV 2081-0 PDF
Published Date:
05/02/2018
Status:
[ Active ]
Publisher:
Society of Motion Picture and Television Engineers
Document Overview
The SMPTE ST 2081 suite of documents defines the mapping of various source image formats onto a singlelink, dual-link and quad-link serial digital interface operating at a nominal rate of 6 Gb/s. This informative “roadmap” describes the documents in the SMPTE ST 2081 suite.
The SMPTE ST 2081 series specify a common virtual interface that is carried on electrical physical interfaces which are also defined in the document suite and on optical physical interfaces..
The diagram of Figure 1 illustrates a simplified ‘Image mapping data flow’ roadmap for the 6G-SDI profile as defined by the SMPTE ST 2081 document suite. The individual roadmaps of the SMPTE ST 2081 standards include additional details of reference standards.
| Edition : | 18 |
| File Size : | 1 file , 260 KB |
| Number of Pages : | 12 |
| Published : | 05/02/2018 |
