The objective of this study was to develop credible design/operation criteria for granular
activated carbon (GAC), magnetized ion exchange (MIEX®) resin, and fixed-bed ion exchange
(IX) processes that enabled the Palmdale Water District Water Treatment Plant, CA (PDWTP)
to limit total trihalomethanes (TTHMs) and haloacetic acids (total of five species, HAA5)
formation up to 60 g/L and 45 g/L, respectively. The process selection conducted by the
PWDTP was based on these design criteria and associated cost-analysis evaluation.
A six months pilot-scale study was conducted at the PDWTP, during which the different
treatment processes were tested at pilot-scale. A total of 90 SDS tests were performed. All
processes successfully reduced SDS-TTHH and SDS-HAA5 below the stipulated goals.
Combining MIEX® treatment operating with a 5% RR and 15% RR, respectively with 50 and 28
mg/L of ferric chloride, decreased SDS-TTHMs to 47 and 52 g/L. The bromide-specific resin
successfully reduced SDS-TTHMs to values below 47 g/L, while the NOM-specific resin
averaged SDS-TTHMs around 46-73 g/L, up to a maximum of 100 g/L. After 120 days of
operation GAC effluent SDS-HAA5 were
| Edition : | Vol. - No. |
| File Size : | 1
file
, 590 KB |
| Note : | This product is unavailable in Ukraine, Russia, Belarus |
| Number of Pages : | 18 |
| Published : | 11/01/2005 |
