SAE J2742_202002 PDF

This SAE standard establishes the minimum construction and performance requirements for a combination cable consisting of 11 conductors and two twisted pairs for use on trucks, trailers, and dollies for 12 VDC nominal applications in conjunction with SAE J2691 (15 pole connectors.) The cable includes both power and unjacketed SAE J1939-15 paired signal circuits along with dual ground wires to accommodate grounding requirements within the constraints of the SAE J2691 terminal capacity.

File Size :	1 file , 350 KB
Note :	This product is unavailable in Ukraine, Russia, Belarus
Number of Pages :	10
Published :	02/24/2020
